Description
Please note that when specifying adaptors the specification of the lower frequency series connector over rides that of the higher frequency connector. eg; N Male – SMA Male, the N-type is used as the reference for the specification.
Specifications:
| Max Frequency | 4 GHz |
| Cable Type Connectors | RG174 |
| Thermal Shock | MIL-STD-107 Test Cond B |
| Salt Spray | MIL-STD-101 Test Cond B |
| Cable Retention | 40 lbs min |
| Coupling Nut Retention | 100lbs Max |
| Durability | 500 matings |
| Vibration | MIL-STD-202 Test Cond B |
| Impedance | 50 Ohm |
| Operational Temperature Range | -65° to 165° C |
| Brand | Pulse |
| Weight [kg] | 0 |
| Component Type | Within Series Adaptor |
