Description
Product Classification Product Type Adapter General Specifications Interface 7-16 DIN Male Interface 2 4.3-10 Female Body Style Straight Mounting Angle Straight Electrical Specifications Connector Impedance 50 ohm Operating Frequency Band 0 – 6000 MHz 3rd Order IMD, typical -163 dBc @ 1800 MHz 3rd Order IMD Test Method Two +43 dBm carriers dc Test Voltage 2500 V Outer Contact Resistance, maximum 1.00 mOhm Inner Contact Resistance, maximum 1.00 mOhm Insulation Resistance, minimum 5000 MOhm
Specifications:
| Connector | 4.3-10(F), 7-16 DIN(M) |
| Brand | Commscope |
| Component Type | Inter Series Adaptor |
