Description
Features:
– Covers all 4G LTE & 3G cellular bands
– Screw mount with anti-rotation mechanism
– Ground plane independent
– Ultra-compact design: Ø 50 x 50.8 mm
– Weatherproof: IP69
SPECIFICATIONS:
| Cable Type Connectors | 5m LL100 with No Connector |
| Operational Temperature Range | -40 to +85 Degree C |
| Frequency Range | 1710 – 2170, 2300 – 2700, 698 – 960 |
| Nominal impedance | 50 |
| Power w | 50 |
| Nominal Gain Dbi | 3.6 / 4.1 / 1.9 |
| Dimensions | Diameter 50mm x 50.8mm |
| Polarisation | Vertical |
| VSWR | <2.5:1 |
| Tuned bandwidth | Full |
| Frequency MHz | 698-960 / 171-2170 / 2500-2700 |
| Brand | RFI |
