Description
These antennas sit in between our market-leading CD7100 and CDQ7100. It is basically a light duty CDQ7100 (i.e. using our CD7100 15.6mm parallel radome and a CD900 Series spring assemble). The CDR7100 Series whips can be removed via the integrated N male connector in the whip and N female connector on the spring assembly.
Features:
– Patented PCB based collinear design offering the ultimate in pattern and gain stability
– Ideal for all new 4G LTE networks with true multi-band coverage
– High gain across all bands making it suiting fringe and rural applications
– Q-Fit® removable whip system for ease of removal in low height environments such as multi-story car parks, car washes or for security
Specifications:
| Packaging | Retail Hang Sell |
| Whip Material | Fiberglass |
| Cable And Connector | 5m of 9006 low loss cable terminated with SMA male connector |
| Frequency Range | 1710 – 2170, 2300 – 2700, 698 – 960 |
| Frequency | 698-960, 1710-2170 & 2300-2700MHz |
| Nominal impedance | 50 |
| Power w | 10 |
| Nominal Gain Dbi | 5.5 / 4.5 / 5.5 |
| VSWR | <2.5:1 |
| Radome Diameter Mm | 16 |
| Tuned bandwidth | Full |
| Length [mm] | 695 |
| Brand | RFI |
