Description
Features:
Multi-Band 380-2700MHz covering UHF and Cellular bands.
Low PIM ‰¤ -150dBc (3rd Order 2x43dBm carriers).
Primarily used for optimizing feeder cable signal distribution.
Suitable for use with simplex and duplex channels, analog or digital radio communications.
Optional N Female termination connector SP3827-23xx-11 range available.
Wide range of coupling values.
Environmental IP 67 Rating.
Specifications:
| Return Loss VSWR | 19dB / 1.25:1 |
| PIM 3rd Order 2x43dBm | ≤ – 150dBc |
| Finish | Painted Black |
| Impedance | 50 Ohms |
| Power Rating Watts | 200 |
| Operational Temperature Range | -30 to +60 C / -22 to +140 F |
| Connector | DIN(F) |
| Frequency Range | 380 – 2700 |
| Dimensions | H 25mm x W 50mm x L 190mm |
| Frequency MHz | 380-2700MHz |
| Brand | RFI |
| Component Type | Directional Coupler |
