RFI 20dB DC-2.5GHz 2W Coaxial In-Line Attenuator With N (M/F) Connector

RFI 20dB DC-2.5GHz 2W Coaxial In-Line Attenuator With N (M/F) Connector

RFI has a wide range of 50 Ohm RF Coaxial In-Line Attenuators in various fixed dB values, power ratings, connector types and frequency ranges. Used primarily in RF multicoupling and bench test and measurement applications, the comprehensive range of coaxial in-line attenuators have excellent return loss and temperature tolerances making them reliable and useful in most applications.

$60.30

Available on backorder

Description

– 2Watt power rating
– DC to 2.5GHz Frequency Range
– Available in 3 , 6 , 10 , 20 and 30dB attenuation values.
– Excellent Return Loss / VSWR across full DC to 2.5GHz bandwidth.



Specifications:

Termination connectors N ( M/F )
Attenuation value 20dB
Attenuation accuracy +/- 1.2dB
Power Rating Maximum 2W
Finish Tri-alloy plating
Impedance 50 Ohms
Power Rating Watts 2W
Operational Temperature Range -40° C to +85° C / -40° F to +185° F
Connector N(m/f)
Frequency Range DC – 2500
Dimensions L 64mm x Dia 21mm / 2.5” x Dia 0.8”
Brand RFI
Component Type Attenuator
