Description
This RF surge protector component is manufactured in a coaxial in-line design with a wide operating frequency range.
Features:
- Broadband performance from DC to 6.4 GHz
- Repetitive lightning strike capability
- Bi-directional protection
- Replaceable gas tube for installation longevity
- Robust brass construction
Specifications:
| Operational Temperature Range | -20 to +65 Degree C |
| Connector | SMA(M) |
| Frequency | 698-960 / 1710-2170 / 2500-2700 MHz |
| Nominal impedance | 50 |
| Power w | 1 |
| Nominal Gain Dbi | 1 / 2 / 2 |
| Polarisation | Linear |
| VSWR | <3.0:1 |
| Tuned bandwidth | Full |
| Horizontal Beamwidth | Omni-directional |
| Width [mm] | 21.5 |
| IP Rating | IP65 |
| Brand | RFI |
| Weight [kg] | 0.0255 |
| Depth [mm] | 6 |
| Height [mm] | 145 |
