Description

General Specifications Device Type Hybrid Application Indoor/Outdoor Color Silver Inner Contact Plating Silver Interface 4.3-10 Female Outer Contact Plating Trimetal Dimensions Height 34 mm | 1.339 in Width 180 mm | 7.087 in Length 180 mm | 7.087 in Electrical Specifications 3rd Order IMD -162 dBc 3rd Order IMD Test Method Two +43 dBm carriers Insertion Loss at Frequency Band 0.3 dB @ 555“2700 MHz Return Loss, minimum 20.8 dB Average Power, maximum 100 W Coupling 6.1 dB Coupling Tolerance ±1.25dB @ 575“2700 MHz | ±1.65dB @ 555“575 MHz Impedance 50 ohm Isolation at Frequency Band 25 dB @ 555“2700 MHz Operating Frequency Band 555 “ 2700 MHz Peak Power, maximum 1 kW Reflected Power, maximum 100 W VSWR 1.2
